Manage Autopilot with multiple tenants

Came back from New Orleans MMS Jazz conference two week ago, and I think I still have jet lag. But my mind is full of new ideas and knowledge, MMS Jazz is such a great event! In one of our session, we talked about automation, I showed how I use Logic Apps, Azure table storage, Azure key vault, and how to use Intune Graph API application permissions. There are lots of information here, that makes me hard to find a starting point to write this post.

In this post I will only talk about Intune Graph API with application permissions and how to use app authentication, I will write other follow up post later still.

Many of us properly manage multiple tenants, right? Sometimes we want to use one script do multi-tasking,  and it’s not very automatic when we have to input our different tenants’ credentials  every single time. Intune Graph API was originally support only delegated permission, but since October 2019, it supports application permissions as well. This is long waiting feature for us, at least for me. With application authentication, we no longer need to input user credentials. But of course, we need to remember handle our application client secret securely.

Graph allows two permission models: Delegated permissions and Application permissions. Delegated permissions are used by apps that have a signed-in user present, it checks if the application and user is allowed to use resources, we can image that’s like using a key to open doors with facial scan required. 🙂 In the other hand, application permissions are used by apps that run without a signed-in user present, it doesn’t not required any user credentials. For example, apps that run as background services or daemons.

Intune Graph Application permission for Autopilot

So how do we know what Graph permissions we need when wants to run some actions? We can check from Microsoft documentation and we can also figured this out by our own. Everything you do in Intune portal, there is Graph behind it. Open up your browser, push F12 for developer mode, go to Network tab. Now when you do some actions in Intune, you will see how the network traffic goes and most fun part here is, you can also see what URI Intune is making the Rest API call. As you can see in the below screenshot, when I was checking an imported Autopilot device details, Intune made GET Rest call to https://graph.microsoft.com/beta/deviceManagement/windowsAutopilotDeviceIdentities , now we go to Microsoft doc check about this windowsAutopilotDeviceIdentities, it said prerequisites for app permission is DeviceManagementServiceConfig.ReadWrite.All and DeviceManagementServiceConfig.Read.All

So by using F12, you can almost learn how to use Intune Graph by ourselves, it shows us how to use filter, expand, select and other queries, and how to make a POST call to create new item. I think this is very cool!

CREATE Azure Application

In some of my posts I have described how to create Azure application, for example https://msendpointmgr.com/2019/06/29/microsoft-graph-intune-fun-create-flow-connector-for-autopilot/. It’s not that difficult create a new application with proper permissions, and I always recommend create your own application, because that application is under your control, and you can add or remove permissions as you wish.

This time I don’t do step by step create Azure Application from Azure Portal, instead I will use PowerShell, since we are going to use this app for multiple tenants, I will also configure this app to support multi tenants. Here is the script, you only need to change $DisplayName if you wants different application name.

After you run this script, it should create a new Azure application for you, double check if application ID is as same as the output of the script.
IMPORTANT: Save the Application secret output, we will need that for later usage

Admin Consent

Now we have created our application and assigned Application permissions, we need to do Admin Consent. By give Admin Consent,  we allow this application access our tenants with those permissions that we assigned.

https://login.microsoftonline.com/common/adminconsent?client_id=10f9be91-4c9b-4427-aa71-143d18abafb5&state=1234&response_type=code&response_mode=query&redirect_uri=https://localhost

How to use this application

Let’s say we have 10 tenants, we have a device that is imported to Autopilot, but we don’t know which tenant this device was imported. Sure we can reinstall the machine and see which tenant it ends up with. But how about let’s try do it in PowerShell and Microsoft Intune Graph way. Here are two scripts with different approach. In both scripts, you need to change $Serial$Tenants, $AppID and $AppSecret to your own values.

The first script below is using Microsoft.Graph.Intune module

The second script below is not using any module, it use POST call gets access token, then use access token to access Autopilot resources

So I hope after reading this long post, you get some ideas how to use Intune Graph application permission with user authentication. Hopefully you find it useful and get some ides for your automation tasks.
